螺牙规格：德制牙（PG）,英制牙[G(PF)],美制牙（NPT）
产品材质：A、C、F部分均采用304不锈钢制成，D部分采用灰色尼龙制成。 B、E部分采用丁晴橡胶（NBR）制成。
防火等级：D部分为UL94V-2,低烟无卤。
防护等级：在规定的卡口范围内，并使用O型密封圈旋紧迫紧头，达到IP68.
颜色种类：A、C、F部位为金属色。D为白色，B、E为黑色。
工作温度：静态：-40℃到100℃，短时间达120℃。动态：-20℃到80℃，短时间达100℃
产品特性：特殊夹紧爪与夹紧圈凹凸相扣之设计，配合迫紧头装配省时便利，夹紧电缆范围大、抗拉力强、可防水、防尘、抗盐、耐酸碱、酒精、油脂及一般溶剂。
更多选择：可根据客户实际需要，特别定制各种材质与尺寸。需要订购时来电咨询。
|
产品型号
|
螺纹规格
|
电缆外径
|
螺纹外径
|
螺纹长度
|
扳手尺寸
|
包装单位
|
|
TLYBFC-EX-M12-H2-03-SS
|
M12X1.5
|
3.1-2
|
12
|
8
|
17/17
|
50
|
|
TLYBFC-EX-M16-H2-04-SS
|
M16X1.5
|
4.1-3
|
16
|
9
|
22/22
|
50
|
|
TLYBFC-EX-M20-H2-06-SS
|
M20X1.5
|
6.1-4.3
|
20
|
10
|
26/26
|
25
|
|
TLYBFC-EX-M25-H2-08-SS
|
M25X1.5
|
8.7-6.4
|
25
|
12
|
32/32
|
25
|
|
TLYBFC-EX-M32-H2-10-SS
|
M32X1.5
|
10-7.7
|
32
|
13
|
41/41
|
10
|
|
TLYBFC-EX-M40-H2-13-SS
|
M40X1.5
|
13-11
|
40
|
15
|
50/50
|
10
|
|
|
|
|
|
|
|
|
|
TLYBFC-EX-PG07-H2-03-SS
|
PG07
|
3.1-2
|
12.5
|
8
|
17/17
|
50
|
|
TLYBFC-EX-PG09-H2-03-SS
|
PG09
|
3.1-2
|
15.2
|
9
|
22/19
|
50
|
|
TLYBFC-EX-PG11-H2-04-SS
|
PG11
|
4.1-3
|
18.6
|
10
|
22/22
|
25
|
|
TLYBFC-EX-PG13.5-H2-05-SS
|
PG13.5
|
5.2-3.5
|
20.4
|
10
|
24/24
|
25
|
|
TLYBFC-EX-PG16-H2-06-SS
|
PG16
|
6.1-4.3
|
22.5
|
10
|
26/26
|
10
|
|
TLYBFC-EX-PG21-H2-08-SS
|
PG21
|
8.7-6.4
|
28.3
|
12
|
32/32
|
10
|
|
|
|
|
|
|
|
|
|
TLYBFC-EX-G3/8-H2-04-SS
|
3/8
|
4.1-3
|
16.6
|
8
|
22/22
|
50
|
|
TLYBFC-EX-G1/2-H2-06-SS
|
1/2
|
6.0-4.3
|
20.95
|
10
|
24/24
|
25
|
|
TLYBFC-EX-G3/4-H2-08-SS
|
G3/4
|
8.7-6.4
|
26.44
|
12
|
32/32
|
25
|
|
TLYBFC-EX-G1"-H2-10-SS
|
G1
|
10-7.7
|
33.25
|
13
|
41/41
|
10
|
|
TLYBFC-EX-G1 1/4-H2-13-SS
|
G1 1/4
|
13-11
|
41.91
|
15
|
50/50
|
10
|
|
|
|
|
|
|
|
|
|
TLYBFC-EX-NPT3/8-H2-04-SS
|
NPT3/8
|
4.1-3
|
17.05
|
8
|
22
|
50
|
|
TLYBFC-EX-NPT1/2-H2-06-SS
|
NPT1/2
|
6.1-4.3
|
21.22
|
10
|
26
|
25
|
|
TLYBFC-EX-NPT3/4-H2-08-SS
|
NPT3/4
|
8.7-6.4
|
26.57
|
12
|
32
|
25
|
|
TLYBFC-EX-NPT1"-H2-10-SS
|
NPT1"
|
10-77
|
33.23
|
13
|
41
|
10
|
|
产品型号
|
螺纹规格
|
电缆外径
|
螺纹外径
|
螺纹长度
|
扳手尺寸
|
包装单位
|
|
TLYBFC-EX-M12-H3-02-SS
|
M12X1.5
|
2.6-1.0
|
12
|
8
|
14/14
|
50
|
|
TLYBFC-EX-M16-H3-04-SS
|
M16X1.5
|
4.2-3
|
16
|
9
|
17/17
|
50
|
|
TLYBFC-EX-M20-H3-05-SS
|
M20X1.5
|
5.2-3.5
|
20
|
10
|
26/26
|
25
|
|
TLYBFC-EX-M25-H3-08-SS
|
M25X1.5
|
8.0-6.2
|
25
|
12
|
32/32
|
25
|
|
TLYBFC-EX-M32-H3-10-SS
|
M32X1.5
|
10-7.7
|
32
|
13
|
41/41
|
10
|
|
TLYBFC-EX-M40-H3-10-SS
|
M40X1.5
|
10-7.7
|
40
|
15
|
50/50
|
10
|
|
|
|
|
|
|
|
|
|
TLYBFC-EX-PG07-H3-02-SS
|
PG07
|
2.6-1.6
|
12.5
|
8
|
14/14
|
50
|
|
TLYBFC-EX-PG09-H3-02-SS
|
PG09
|
2.6-1.6
|
15.2
|
9
|
17/17
|
50
|
|
TLYBFC-EX-PG11-H3-04-SS
|
PG11
|
4.2-3
|
18.6
|
10
|
22/22
|
25
|
|
TLYBFC-EX-PG13.5-H3-05-SS
|
PG13.5
|
5.0-3.5
|
20.4
|
12
|
24/24
|
25
|
|
TLYBFC-EX-PG16-H3-05-SS
|
PG16
|
5.2-3.5
|
22.5
|
12
|
26/26
|
10
|
|
TLYBFC-EX-PG21-H3-08-SS
|
PG21
|
8.0-6.2
|
28.3
|
13
|
32/32
|
10
|
|
TLYBFC-EX-PG29-H3-10-SS
|
PG29
|
10-7.7
|
37
|
15
|
41/41
|
5
|
|
TLYBFC-EX-PG36-H3-10-SS
|
PG36
|
10-7.7
|
47
|
15
|
57/52
|
5
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TLYBFC-EX-G3/8-H3-04-SS
|
3/8
|
4.1-3
|
16.6
|
8
|
22/22
|
50
|
|
TLYBFC-EX-G1/2-H3-06-SS
|
1/2
|
6.0-4.3
|
20.95
|
10
|
24/24
|
25
|
|
TLYBFC-EX-G3/4-H3-08-SS
|
G3/4
|
8.7-6.4
|
26.44
|
12
|
32/32
|
25
|
|
TLYBFC-EX-G1"-H3-10-SS
|
G1
|
10-7.7
|
33.25
|
13
|
41/41
|
10
|
|
TLYBFC-EX-G1 1/4-H3-13-SS
|
G1 1/4
|
13-11
|
41.91
|
15
|
50/50
|
10
|
|
|
|
|
|
|
|
|
|
TLYBFC-EX-NPT3/8-H3-04-SS
|
NPT3/8
|
4.1-3
|
17.05
|
8
|
22
|
50
|
|
TLYBFC-EX-NPT1/2-H3-06-SS
|
NPT1/2
|
6.1-4.3
|
21.22
|
10
|
26
|
25
|
|
TLYBFC-EX-NPT3/4-H3-08-SS
|
NPT3/4
|
8.7-6.4
|
26.57
|
12
|
32
|
25
|
|
TLYBFC-EX-NPT1"-H3-10-SS
|
NPT1"
|
10-77
|
33.23
|
13
|
41
|
10
|
