适用范围：
1.1区、2区危险场所；
2.llA、I1B、IC类爆炸性气体环境。
产品特点：
1.采用黄铜、不锈钢制成；
2.具有快捷安装、安全可靠、防护性能好、防爆性能优越等特点；
3.适用于夹持和固定各种类型的钢芯、钢丝编织或带状铠装电缆，用于必须对电缆芯线部分隔爆及外壳气体密封达IP66的场所，防爆标志为：Exell的等效于|12GExell（欧标）Exdll等效于l12GExdll（欧标）
Applications：1.Hazardous:division182；
2.Explosive gas atmosphere:class llA，IB，lIC.
Features：
1. It*s made of copper or stainless steel material;
2. With reliable installation, good protecting and explosion-proof function;
3. Iso lating gasketing tube is suitable for clamping or fixing steel wire knit or anmour cable, its cable core and enclosure gassealing protection must be IP66, Ex-mark: Exe ll is equal to I12G Exe ll(Europen Standard)；Exe ll is equal to I12G Exe ll(Europen Standard)
型号
Model number
|
螺纹规格
Thread Dimension
|
电缆外径
Outer diameter of cable (mm)
|
螺纹长度L 1
Tread length
|
长度
Length（mm）
|
订货号
Article No.
|
出线
Outlet A
|
进线
Incoming line B
|
|
TLYBFC-EXM.KZ.M16
|
M16×1.5
|
5-8
|
7-15
|
15
|
67
|
89 00 040 0160 08
|
|
TLYBFC-EXM.KZ.M20
|
M20×1.5
|
5-12
|
8-15
|
15
|
67
|
89 00 040 0200 08
|
|
TLYBFC-EXM.KZ.M25
|
M25×1.5
|
8-17
|
11-20
|
15
|
71
|
89 00 040 0250 08
|
|
TLYBFC-EXM.KZ.M32
|
M32×1.5
|
11-22
|
14-27
|
17
|
76
|
89 00 040 0320 08
|
|
TLYBFC-EXM.KZ.M40
|
M40×1.5
|
14-28
|
19-33
|
17
|
76
|
89 00 040 0400 08
|
|
TLYBFC-EXM.KZ.M50
|
M50×1.5
|
16-33
|
22-40
|
17
|
94
|
89 00 040 0500 08
|
|
TLYBFC-EXM.KZ.M63
|
M63×1.5
|
29-43
|
29-50
|
17
|
98
|
89 00 040 0630 08
|
|
TLYBFC-EXM.KZ.M75
|
M75×1.5
|
38-57
|
35-63
|
17
|
112
|
89 00 040 0750 08
|
|
TLYBFC-EXM.KZ.M85
|
M85×1.5
|
38-72
|
41-77
|
18
|
114
|
89 00 040 0850 08
|
|
TLYBFC-EXM.KZ.M90
|
M90×1.5
|
38-72
|
41-77
|
18
|
126
|
89 00 040 0900 08
|
|
TLYBFC-EXM.KZ.M100
|
M100×1.5
|
48-83
|
55-90
|
18
|
126
|
89 00 040 5100 08
|
|
TLYBFC-EXM.KZ.M110
|
M110×1.5
|
48-94
|
61-104
|
18
|
128
|
89 00 040 5110 08
|
